Plugin Configuration Fields

Overview

Configuration fields allow Pinpoint users with admin permissions to configure your plugin integration from the Pinpoint UI — things like API keys, base URLs, webhook secrets, and other settings your plugin needs to operate.

Once saved by the admin, these values are automatically included in every request Pinpoint makes to your plugin, so you don't need to manage credentials yourself.

How Configuration Fields Work

📘

Currently all changes done to the Meta Endpoint (including configuration fields changes) require refresh on the already registered plugin. This needs to be done by the Pinpoint team, please reach out to [email protected].

Setup Flow

1. You define configurationFormFields in your plugin's Meta Endpoint response.
2. Pinpoint renders these as a form in the Integrations → My Plugins → Configure panel.
3. The admin fills in the values (e.g. their API key) and saves.
4. Pinpoint stores the values securely (sensitive fields are encrypted).
5. On every subsequent request to your plugin — meta, submit, webhook process — Pinpoint automatically includes the saved values as configurationValues in the request payload (or as HTTP headers if useAsHttpHeader is set).

What It Looks Like in the UI

When an admin opens the Configure panel for their plugin, they see a form rendered from your configurationFormFields definition:

Above: The Configure panel showing API Key (sensitive/masked), Base URL, and an optional persisted field.

Defining Configuration Fields

Configuration fields are defined in the response from your Meta Endpoint (the root endpoint Pinpoint calls to register your plugin).

{
  version: '2.0.0',
  name: 'ExampleAssessments',
  actions: [...],
  configurationFormFields: [
    {
      key: 'apiKey',
      label: 'API Key',
      description: 'Your ExampleAssessments API key',
      type: 'string',
      required: true,
      sensitive: true,
      placeholder: 'e.g. sk_live_abc123',
    },
    {
      key: 'baseUrl',
      label: 'Base URL',
      description: 'Your ExampleAssessments API base URL',
      type: 'string',
      required: true,
      defaultValue: 'https://api.example-assessments.com',
      placeholder: 'e.g. https://api.example-assessments.com',
    },
  ]
}

Field Properties

Schema

Select Option Object

Field Types

string

The standard type for all configuration fields. Renders as a text input (or multiline textarea if multiline: true). Values are stored but not automatically persisted between actions.

{
  key: 'apiKey',
  label: 'API Key',
  type: 'string',
  required: true,
  sensitive: true,
}

When you provide one of singleSelectOptions, multiSelectOptions, checkboxOptions, radioOptions, then the field will be displayed as a respective field type with provided options. Please see the section below.

persisted_string

Same as string but the value is persisted back to the configuration after each successful action. This is useful for round-trip values — when your plugin writes a value back via the persist response field and you want it to survive across multiple action submissions.

A common use case is storing a value that your external system returns (e.g. last employee ID - for incremental IDs, a "most recently submitted" tracker for debugging).

{
  key: 'mostRecentFirstName',
  label: 'Most Recent First Name',
  description: 'The most recent first name submitted (for debugging)',
  type: 'persisted_string',
  sensitive: false,
}

💡

persisted_string fields can be updated programmatically using the persist field in your action submit result response.

Special Behaviors

Sensitive Fields

Fields marked sensitive: true are treated as credentials:

• Values are encrypted at rest in Pinpoint's database.
• In the Configure UI, the existing value is masked (shown as ****). The admin must type a new value to update it.
• Sensitive values are never sent to the frontend — only transmitted server-to-server to your plugin endpoints.

{
  key: 'apiKey',
  label: 'API Key',
  type: 'string',
  sensitive: true,
  required: true,
  placeholder: 'e.g. sk_live_abc123',
}

Always set sensitive: true for API keys, passwords, webhook secrets, and any other credential.

Sending Values as HTTP Headers

If your plugin authenticates via HTTP headers (rather than reading credentials from the request body), set useAsHttpHeader to the header name you want the value sent under.

When useAsHttpHeader is set:

• The value is NOT included in configurationValues in the request payload.
• Instead, it is added as an HTTP request header on every request Pinpoint makes to your plugin.

{
  key: 'apiKey',
  label: 'API Key',
  type: 'string',
  sensitive: true,
  required: true,
  useAsHttpHeader: 'X-API-Key',
}

With this configuration, Pinpoint will send:

POST /your-plugin/meta
X-API-Key: sk_live_abc123

And configurationValues in the payload will not contain apiKey.

💡

useAsHttpHeader and configurationValues are mutually exclusive for a given field. A field with useAsHttpHeader set will only appear in the request headers, not in the payload.

Action-Scoped Fields

By default, all configuration fields are sent on every request to your plugin. If you need certain fields to only be sent for a specific action type, set actionType:

{
  key: 'backgroundCheckPackageId',
  label: 'Default Package ID',
  type: 'string',
  actionType: 'createBackgroundCheck',
  description: 'Default background check package to use if not overridden in the form',
}

Valid values:

• createAssessment
• createBackgroundCheck
• exportCandidate

When actionType is omitted, the field is sent to all action endpoints.

Read-Only Fields

Fields marked readonly: true are displayed to the admin but cannot be edited. This is useful for showing system-generated values your plugin provides — such as a webhook URL that the admin needs to copy into a third-party system.

{
  key: 'webhookUrl',
  label: 'Webhook URL',
  description: 'Copy this URL into your provider dashboard to enable webhooks',
  type: 'string',
  readonly: true,
  defaultValue: 'https://app.pinpointhq.com/your-webhook-url',
}

Select / Radio / Checkbox Fields

Configuration fields support the same selection UI components as action form fields. These let admins choose from a fixed set of options rather than typing freeform text.

Radio buttons (max 3 options) — good for binary toggles:

{
  key: 'environment',
  label: 'Environment',
  description: 'Which environment to use',
  type: 'string',
  defaultValue: 'production',
  radioOptions: [
    { label: 'Production', value: 'production' },
    { label: 'Sandbox', value: 'sandbox' },
  ],
}

Single-select dropdown — for longer option lists:

{
  key: 'region',
  label: 'Region',
  type: 'string',
  singleSelectOptions: [
    { label: 'US', value: 'us' },
    { label: 'EU', value: 'eu' },
    { label: 'APAC', value: 'apac' },
  ],
}

Multi-select dropdown — for longer option lists with an option to multiple options:

{
  key: 'region',
  label: 'Region',
  type: 'string',
  multiSelectOptions: [
    { label: 'US', value: 'us' },
    { label: 'EU', value: 'eu' },
    { label: 'APAC', value: 'apac' },
  ],
}

How Configuration Values Are Sent to Your Plugin

Once an admin saves their configuration, Pinpoint automatically includes the values in every request to your plugin.

In the Payload (configurationValues)

For fields without useAsHttpHeader, values are sent as a configurationValues array:

{
  "payloadVersion": "1.0.0",
  "key": "createBackgroundCheck",
  "formFields": [],
  "configurationValues": [
    { "key": "apiKey", "value": "sk_live_abc123" },
    { "key": "baseUrl", "value": "https://api.example.com" }
  ],
  "webhookUrl": "https://app.pinpointhq.com/..."
}

This applies to:

• Action Meta Endpoint requests (when building the form)
• Action Submit Endpoint requests (when the user submits the form)
• Webhook Process Endpoint requests (when forwarding a webhook payload)
• Base Meta Endpoint requests (during plugin registration/handshake)

As HTTP Headers

For fields with useAsHttpHeader set, the value is sent as a header on every request:

POST /your-plugin/createBackgroundCheck/meta
X-Example-Checks-Key: sk_live_abc123
X-Example-Base-URL: https://api.example.com
Content-Type: application/json

{ "payloadVersion": "1.0.0", ... }

Reading Configuration Values in Your Plugin

Configuration values arrive as an array of { key, value } objects. Use a helper to convert them to a hash for easy access:

Node.js:

function getConfigValues(payload) {
  return (payload.configurationValues || []).reduce((acc, { key, value }) => {
    acc[key] = value;
    return acc;
  }, {});
}

// Usage
const config = getConfigValues(payload);
const apiKey = config.apiKey;
const baseUrl = config.baseUrl;

def configuration_values_from_payload(payload)
  payload&.fetch('configurationValues', nil)
         &.map { [_1['key'], _1['value']] }
         &.to_h || {}
end

# Usage
config = configuration_values_from_payload(payload)
api_key = config['apiKey']
base_url = config['baseUrl']

Real-World Examples

API Key + Base URL (most common)

The most common pattern: a sensitive API key and a configurable base URL. The API key is sent as an HTTP header so your plugin can authenticate without parsing the payload body.

configurationFormFields: [
  {
    key: 'apiKey',
    label: 'API Key',
    description: 'Your ExampleAssessments API key',
    type: 'string',
    required: true,
    sensitive: true,
    useAsHttpHeader: 'X-Example-Key',
    placeholder: 'e.g. sk_live_abc123',
  },
  {
    key: 'baseUrl',
    label: 'Base URL',
    description: 'Your ExampleAssessments API base URL',
    type: 'string',
    required: true,
    sensitive: false,
    useAsHttpHeader: 'X-Example-Base-URL',
    placeholder: 'e.g. https://api.example.com',
  },
]

Username + Password Authentication

For providers using basic auth or credential-based authentication:

configurationFormFields: [
  {
    key: 'username',
    label: 'Username',
    description: 'Your ExampleAssessments API username',
    type: 'string',
    required: true,
    sensitive: false,
    placeholder: 'e.g. hr-user',
  },
  {
    key: 'password',
    label: 'Password',
    description: 'Your ExampleAssessments API password',
    type: 'string',
    required: true,
    sensitive: true,
    placeholder: 'e.g. ••••••••••••',
  },
  {
    key: 'baseUrl',
    label: 'Base URL',
    description: 'The ExampleAssessments API base URL',
    type: 'string',
    required: true,
    sensitive: false,
    placeholder: 'e.g. https://api.sovaonline.com/integrations/hr-user/v4',
  },
]

Multiple Secrets (API Key + Webhook Secret)

When your provider requires a separate secret for webhook signature verification:

configurationFormFields: [
  {
    key: 'apiKey',
    label: 'API Key',
    description: 'Your ExampleAssessments API key',
    type: 'string',
    required: true,
    sensitive: true,
    placeholder: 'e.g. 12345678-abcd-1234-abcd-1234567890ab',
  },
  {
    key: 'secretKey',
    label: 'Secret Key',
    description: 'Your ExampleAssessments secret key',
    type: 'string',
    required: true,
    sensitive: true,
    placeholder: 'e.g. 12345678-abcd-1234-abcd-1234567890ab',
  },
  {
    key: 'webhookSecret',
    label: 'Webhook Secret',
    description: 'Your ExampleAssessments webhook secret for signature verification',
    type: 'string',
    required: true,
    sensitive: true,
    placeholder: 'e.g. 12345678-abcd-1234-abcd-1234567890ab',
  },
]

Default Value + Radio Toggle

For a boolean setting with a default:

configurationFormFields: [
  {
    key: 'apiKey',
    label: 'API Key',
    type: 'string',
    required: true,
    sensitive: true,
  },
  {
    key: 'showResultsToCandidate',
    label: 'Show Results to Candidate',
    description: 'Allow candidates to view their results when completed',
    type: 'string',
    required: false,
    sensitive: false,
    defaultValue: 'false',
    radioOptions: [
      { label: 'Enabled', value: 'true' },
      { label: 'Disabled', value: 'false' },
    ],
  },
]

Displaying a System-Generated Webhook URL

When your provider requires you to register a webhook URL in their dashboard, you can display the platform's webhook URL as a read-only field so admins can easily copy it:

configurationFormFields: [
  {
    key: 'apiKey',
    label: 'API Key',
    type: 'string',
    required: true,
    sensitive: true,
  },
  {
    key: 'webhookUrl',
    label: 'Webhook URL',
    description: 'Copy this URL into your Shortlister dashboard under Webhooks',
    type: 'string',
    readonly: true,
    defaultValue: webhook_url,   # provided by the framework at registration time
  },
]

Default Base URL with Override

When your plugin has a standard production URL but some clients may need to point to a different environment:

configurationFormFields: [
  {
    key: 'apiKey',
    label: 'API Key',
    type: 'string',
    required: true,
    sensitive: true,
    placeholder: 'e.g. 12345678-abcd-1234-abcd-123456789abc',
  },
  {
    key: 'baseUrl',
    label: 'Base URL',
    description: "The Predictive Index API base URL (default: #{DEFAULT_BASE_URL})",
    type: 'string',
    required: true,
    sensitive: false,
    defaultValue: DEFAULT_BASE_URL,
    placeholder: "e.g. #{DEFAULT_BASE_URL}",
  },
]
